Product Details
＋
Specifications
| General | |
|---|---|
| Platform Technology | Intel vPro Platform |
| Type | Personal computer |
| Product Form Factor | Mini tower |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Processor / Chipset | |
|---|---|
| CPU | Intel Core i5 |
| Clock Speed | 2.9 GHz |
| Max Turbo Speed | 4.8 GHz |
| Number of Cores | 8-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| Processor Main Features | Intel Turbo Boost Technology 2 |
| Chipset Type | Intel Q570 |
| Cache Memory | |
|---|---|
| Installed Size | 16 MB |
| Cache Per Processor | 16 MB |
| RAM | |
|---|---|
| Installed Size | 4 GB / 128 GB (max) |
| Technology | DDR4 SDRAM - non-ECC |
| Form Factor | DIMM 288-pin |
| Slots | 4 (total) / 2 (empty) |
| Configuration Features | 2 x 8 GB |
| Hard Drive | |
|---|---|
| Type | HDD |
| Capacity | 1TB |
| Storage Controller | |
|---|---|
| Type | 1 x SATA |
| Controller Interface Type | SATA 6Gb/s |
| Optical Storage | |
|---|---|
| Type | DVD-Writer |
| Monitor | |
|---|---|
| Monitor Type | None. |
| Graphics Controller | |
|---|---|
| Graphics Processor | Intel UHD Graphics 630 |
| Video Interfaces | DisplayPort |
| Audio Output | |
|---|---|
| Sound Output Mode | 4 channel surround |
| Compliant Standards | High Definition Audio |
| Speakers Included | 1 x mixed channel |
| Input Device | |
|---|---|
| Type | Mouse (on selected markets only), keyboard (on selected markets only) |
| Keyboard | |
|---|---|
| Keyboard Name | Dell KM5221W Pro Wireless Keyboard and Mouse Combo |
| Connectivity | Wireless |
| Mouse | |
|---|---|
| Connectivity | Wireless |
| Networking | |
|---|---|
| Ethernet Controller | Intel I219-LM |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Expansion / Connectivity | |
|---|---|
| Bays | 1 (total) / 0 (free) x external 5.25" Slim Line ¦ Internal 3.5" ¦ Internal 2.5" |
| Slots | 1 (total) / 1 (free) x PCIe 4.0 x16 - full-height ¦ 1 (total) / 1 (free) x PCIe x16 - full-height (x4 mode) ¦ 1 (total) / 1 (free) x PCIe x1 - full-height ¦ 1 (total) / 1 (free) x PCI - full-height ¦ 2 (total) / 2 (free) x M.2 Card - 2230 ¦ 1 (total) / 0 (free) x M.2 Card - 2230/2280 |
| Interfaces | 2 x USB 3.2 Gen 2 (1 in front) ¦ 2 x USB 2.0 (2 in front) (one of them with PowerShare) ¦ 1 x USB-C 3.2 Gen 2 (1 in front) ¦ 1 x PS/2 keyboard ¦ 1 x PS/2 mouse ¦ 1 x headphones/microphone (1 in front) ¦ 1 x serial ¦ 2 x DisplayPort ¦ 3 x USB 3.2 Gen 1 ¦ 2 x USB 2.0 (supports SmartPower On) ¦ 1 x LAN (Gigabit Ethernet) |
| Miscellaneous | |
|---|---|
| Included Accessories | M.2 caddy |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately), padlock loop |
| Security Slot Type | Kensington security slot |
| Pricing Type | Build To Stock (BTS) |
| Power | |
|---|---|
| Device Type | Power supply |
| Voltage Required | AC 90-264 V (50/60 Hz) |
| Power Provided | 260 Watt |
| 80 PLUS Certification | 80 PLUS Platinum |
| Operating System / Software | |
|---|---|
| OS Provided | Windows 10 Pro 64-bit Edition |
| Software | Microsoft Office (30 days trial), Dell Applications for Windows 10, Cyberlink Media Suite Essentials without Media, Dell Optimizer |
| Environmental Standards | |
|---|---|
| EPEAT Compliant | EPEAT Gold |
| ENERGY STAR Certified | Yes |
| Dimensions & Weight | |
|---|---|
| Width | 6.7 in |
| Depth | 11.8 in |
| Height | 14.4 in |
| Weight | 14.46 lbs |
| Environmental Parameters | |
|---|---|
| Min Operating Temperature | 50 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 20 - 80% (non-condensing) |
