Platform

Desktop

Market Segment

Enthusiast Desktop

Product Family

AMD Ryzen™ Processors

Product Line

AMD Ryzen™ 7 Processors

AMD PRO Technologies

No

Consumer Use

Yes

Regional Availability

Global

Former Codename

"Raphael AM5"

Architecture

"Zen 4"

# of CPU Cores

8

Multithreading (SMT)

Yes

# of Threads

16

Max. Boost Clock

Up to 5.3GHz

Base Clock

3.8GHz

L1 Cache

512KB

L2 Cache

8MB

L3 Cache

32MB

Default TDP

65W

Processor Technology

TSMC 5nm FinFET

I/O Die Technology

TSMC 6nm FinFET

CPU Compute Die Size

71mm²

I/O Die Size

122mm²

Package Die Count

2

Unlocked for Overclocking

Yes

Memory Overclocking

AMD EXPO™ Memory Overclocking Technology

Precision Boost Overdrive

Yes

Curve Optimizer

Yes

AMD Ryzen™ Master

Yes

CPU Socket

AM5

Supporting Chipsets

A620, X670E, X670, B650E, B650

CPU Boost Technology

Precision Boost 2

Instruction Set

x86-64

Supported Extensions

AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX( ), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64

Thermal Solution

AMD Wraith Prism

Max. Operating Temperature

95°C

Launch Date

1/14/2023

Operating System Support

Windows 11 - 64-Bit Edition, Windows 10 - 64-Bit Edition, RHEL x86 64-Bit, Ubuntu x86 64-Bit

Connectivity

USB Type-C® Support, Native USB 3.2 Gen 2 (10Gbps) Ports: 4, Native USB 3.2 Gen 1 (5Gbps) Ports: 0, Native USB 2.0 (480Mbps) Ports: 1, Native SATA Ports: 0

PCI Express Version

PCIe® 5.0

Native PCIe Lanes

Total/Usable: 28 / 24

Additional PCIe Lanes

AMD X670E: 12x Gen4, AMD X670: 12x Gen4, AMD B650E: 8x Gen4, AMD B650: 8x Gen4

NVMe Support

Boot, RAID0, RAID1, RAID10

System Memory Type

DDR5

Memory Channels

2

Max. Memory

128GB

System Memory Subtype

UDIMM

Max Memory Speed

2x1R DDR5-5200, 2x2R DDR5-5200, 4x1R DDR5-3600, 4x2R DDR5-3600

ECC Support

Yes (Requires motherboard support)

Graphics Capabilities

Integrated Graphics

Graphics Model

AMD Radeon™ Graphics

Graphics Core Count

2

Graphics Frequency

2200 MHz

USB Type-C DisplayPort

Alternate Mode

Product IDs

Boxed: 100-100000592BOX, Tray: 100-000000592

Key Features

Supported Technologies: AMD EXPO™ Technology, AMD Ryzen™ Technologies
